Arxtron’s Control Signal Management boards provide seamless compatibility between the sensing side (e.g., optical sensors, switch probes, safety interlocks) and the output side (e.g., PLCs, active or passive signals). These boards are designed to ensure accurate monitoring and control of fixture-level signals, allowing safe and efficient operation during testing.
Whether it’s detecting the presence of DUTs or monitoring safety interlocks, Arxtron’s Control Signal Management systems integrate multiple sensor types and convert their signals into actionable output for further automation or PLC-driven processes. This system ensures that both sensing and output components work together, eliminating mismatches and optimizing performance.
Applications & Benefits
Presence Sensing
Verify correct DUT placement before initiating tests, ensuring alignment with test protocols
Safety Interlock Monitoring
Safeguard operators by detecting hand positions or fixture blockages, preventing unsafe conditions
NC and NO Contact Management
Manage normally closed (NC) and normally open (NO) inputs for flexible control and precise operations across sensing and output systems
Technical Specifications
| Parameter | Specification |
|---|---|
|
Input Voltage Range |
3.3V to 24V DC |
|
Current Consumption |
<10mA standby, <25mA active |
|
Reset Output |
Open-drain or push-pull (active low or configurable) |
|
Interfaces |
Header pins |
|
Form Factor |
50mm x 30mm module (custom sizes available) |
|
Use Case Integration |
Functional testers, DUT supervision, test PC control, robotics |
