High-Speed In-System Programming for Modern Production Lines
FlashRunner 2.0 – Advanced In-System Programmer
FlashRunner 2.0 – Advanced In-System Programmer
- Eliminates the need for pre-programmed devices by enabling direct in-circuit programming.
- Reduces production time with fast, parallel, and reliable programming operations.
- Enhances traceability and quality with built-in serialization and logging.
- Supports flexible integration into both manual test stations and automated ATE setups.
- Future-proofs device support through an open, script-based architecture.
FlashRunner 2.0 is an advanced In-System Programmer (ISP) developed by SMH Technologies, designed to deliver fast, flexible, and reliable programming of microcontrollers, serial memories, and programmable devices directly within the target system. With robust scripting capabilities, high-speed interfaces, and full automation readiness, FlashRunner 2.0 is suited for both manual and automated production environments across multiple industries.
Key Features
Flexible Programming Architecture: Supports a wide range of protocols such as JTAG, SWD, SPI, I2C, and UART.
Open Scripting Engine: Fully scriptable via FPL2™ language for complete control of the programming process.
Fast & Reliable: High-speed programming and verification routines ensure rapid production throughput.
Integrated Debugging & Logging: Real-time error reporting and log generation for traceability.
Automation-Ready: Can be embedded in ATEs, robotic systems, or used as a standalone programmer.
Secure Programming: Optional encryption ensures secure firmware handling and distribution.
Benefits to the Customer
Programmable Flexibility
Adapt to a wide variety of devices and firmware versions with no hardware changes
Scalable Deployment
Can be used from prototype phases to fully automated production lines
Low Total Cost of Ownership
Single-unit or networked multi-station setup without recurring software costs
Fast Time-to-Market
Simplifies programming setup with minimal learning curve and fast execution
Quality & Compliance
Integrated serialization and logging support traceability for ISO and industry standards
Future-Ready
Ongoing firmware and script updates ensure long-term device support and compatibility
Technical Specifications
| Specification | Description |
|---|---|
|
Programming Channels |
1 (expandable via networked units |
|
Supported Interfaces |
JTAG, SWD, SPI, I2C, UART, BDM, CAN, etc |
|
Host Communication |
Ethernet, USB, RS232 |
|
Operating Modes |
Standalone, remote, automated |
|
Supported Voltages |
Programmable I/O from 1.2V to 5V |
|
Scripting Language |
FPL2™ |
|
Traceability |
Full serialization, log export, and statistics |
|
Form Factor |
Compact, bench-top or fixture integration |
Supported Applications/ Products
Medical Device
Firmware Uploads
Microcontroller-Based Control Boards
Industrial Automation Systems
Automotive Sensors
& ECU
Smart Home &
IoT Modules
